Low Build Batch Mixer

The new Low Build Batch Mixer is multifunctional with an integrated feeding belt. This batch mixer comes in two different variants, as ”Stand alone unit” and as an ”Integrated unit”. The integrated batch mixer communicates with the filler which tells the batch mixer when it requires more substrate to the filler. The integrated batch mixer is controlled from the filler’s control system. The integrated batch mixer requires a compatible filling machine. The stand alone unit includes its own PLC and HMI for stand alone operation. It does not communicate with the rest of the production line. The Low Build Batch Mixer has exchangeable wear plates which are easy to replace and easy to handle. The machine is automized with a digital control system and remote access system. The watering unit has a built-in timer where it is easy to set the desired time for watering of the substrate. For the Low Build Batch Mixer no compressed air is needed which makes the machine more silent.

Specifications

  • Dimensions (LxWxH) mm: 2680 x 2720 x 2500
  • Hopper capacity (liters): Max 1,5 m3 depending on substate
  • Weight: 1250 kg
  • Standard power supply, V/Hz/Amps: 3x400v+Neutral+GND 50/60hz
  • Power requirement, kW: 5kW

Downloads

Key Features

Improved design with integrated media feeding belt for more efficient feeding

Even and homogeneous mixing of growing media components

Short mixing time due to agitator design avoiding damaging of growing substrate structure

Quick filling of mixer from Big Bale Dosage Bunker

Communication between mixer and filling unit for automatic feeding

Self-cleaning rollers in feeding belts ensure longer life

Robust construction

Built-in timer for easy setting of irrigation time for the substrate

Lid with sliding function with built-in safety switch for safe handling during the mixing process
